GE IC660BBR101 Relay Output Block, 230 V dc
General info
| Manufacture | GE |
| Item No | IC660BBR101 |
| Article number | IC660BBR101 |
| Series | GE FANUC |
| Origin | United States（US） |
| Dimension | 180*180*30(mm) |
| Weight | 0.8 kg |
| Customs Tariff Number | 85389091 |
| Type | Output Block |
Detailed data
GE IC660BBR101 Relay Output Block, 230 V dc
The IC660BBR101 is a Normally Open Relay Output Block manufactured by GE Fanuc. The block comes with 16 output circuits grouped into four groups, each with four outputs. Each output can be powered by either AC or DC. Because of its normally open design, the block’s contacts are separated by default until power is applied to close the gap existing between circuit components.
The relay block has a rated voltage of 115 VAC, which is the factory setting, to 230 VAC. The voltage selection is made possible by jumpers located on the block’s assembly. The block runs on a load current of 2 Amps. Output circuit group isolation is 1500VAC. IC660BBR101 is useful in a variety of low power applications such as relays, lamps, and contactors.
