GE IC660BBD025 DC 32-Circuit Source/Sink I/O Module
General info
| Manufacture | GE |
| Item No | IC660BBD025 |
| Article number | IC660BBD025 |
| Series | GE FANUC |
| Origin | United States（US） |
| Dimension | 180*180*30(mm) |
| Weight | 0.8 kg |
| Customs Tariff Number | 85389091 |
| Type | I/O Module |
Detailed data
GE IC660BBD025 DC 32-Circuit Source/Sink I/O Module
The IC660BBD025 is a Block I/O from the Genius I/O Block series. This device is mainly used to implement distributed I/O architecture as the IC660BBD025 is a fully-functional Genius I/O node that comes with Thirty-Two (32) I/O circuits, a built-in Genius communication terminal, and an integrated Hand Held Monitor (HHM) port. The IC660BBD025 is formerly produced by GE Fanuc Automation however, the product series and other automation devices have been acquired by Emerson Automation. This module supports remote installation, near the machine or process being controlled as the IC660BBD025 is capable of communicating with the controller up to 7500 feet away.
It also comes with 32 I/O points. The load current rating of the block is 0.5 Amps. The I/O block can interface with different input devices, switches, and field devices. The IC660BBD025 I/O sink block can be easily configured and it can be used as an input or an output device. The front side of the block is equipped with different ports and LED indicators. A monitor port is available on the top of the block that can be used to connect with a programmable controller or monitoring device. Below the monitoring port, Serial Port 1 and Serial Port 2 are available along with the Shield In Port and the Shield Out Port.
