GE IC660BBD024 High-Density 32-Point Discrete Sourcing I/O Module
General info
| Manufacture | GE |
| Item No | IC660BBD024 |
| Article number | IC660BBD024 |
| Series | GE FANUC |
| Origin | United States（US） |
| Dimension | 180*180*30(mm) |
| Weight | 0.8 kg |
| Customs Tariff Number | 85389091 |
| Type | I/O Module |
Detailed data
GE IC660BBD024 High-Density 32-Point Discrete Sourcing I/O Module
The IC660BBD024 supports Genius Bus protocol for communication with partner device that is compatible with the mentioned protocol. Specifically, bus controllers such as IC66 CBB902 or CBB 903, any version; or model IC66 CBB900 or CBB901 version 1.3 or later may be used. Additionally, it may also be configured using the IC66 HHM501 Hand-Held monitor. For Bus Switching Module (BSM), the IC66 BSM021 is compatible for use with the IC660BBD024 block I/O.
The IC660BBD024 I/O block can also work with 2-wire and 3-wire proximity switches, along with relays, contactors, and lamps. The 32 identical I/O points on the front panel can be easily configured. A corresponding LED indicator next to the contact illuminates when a connection is made with the contact. The block-to-block isolation rating of the GE Fanuc IC660BBD024 I/O block is 850 Volts. It has a maximum ripple of 10% for 12 to 24 Volts and of 1% for 5 Volts. The IC660BBD024 I/O block has a power supply dropout of 4 milliseconds at 12 Volts, and one of 20 milliseconds at 24 Volts. During the installation of the block, proper handling should be ensured. The block comes with an open enclosure and hence should be kept in a clean location that has no airborne contaminants. It can be mounted in an upward or downward position with at least 2 inches of space between adjacent blocks. The operating temperature range for the IC660BBD024 I/O block should be set between 0 and 60 degrees Celsius with a maximum humidity level of 95% non-condensing humidity.
