GE IC660BBD022 I/O Block
General info
| Manufacture | GE |
| Item No | IC660BBD022 |
| Article number | IC660BBD022 |
| Series | GE FANUC |
| Origin | United States（US） |
| Dimension | 180*180*30(mm) |
| Weight | 0.8 kg |
| Customs Tariff Number | 85389091 |
| Type | I/O Block |
Detailed data
GE IC660BBD022 I/O Block
This module is a panel-mounted, stand-alone device that cones with an open-type enclosure therefore, must be installed within an enclosure that provides adequate protection against industrial contaminants. This module can be remotely mounted away from partner devices at a maximum distance of 7500 feet. It also permits daisy-chaining of other I/O blocks to form a Genius I/O network. The module's operation can be configured locally using a hand-Held Monitor (HHM) via the HHM port installed on top of the terminal assembly. It may also be configured remotely using the programming software of the host controller.
The IC660BBD022 I/O block is a 16-circuit enabled source I/O block manufactured by GE Fanuc. It runs with 24 Volts DC power and it can be used along with 2-wire and 3-wire sensors. This Genius I-O device has a load current of 2 Amps, and this DC-powered block is intelligent and it can be configured easily in order to be used as a sensor or an actuator device. It comes with other configurable features that include output power default, a selectable input filter time, and an output pulse test capability. The IC660BBD022 I/O block is manufactured with diagnostics and safety measures that can easily alert the operators for run time and operational errors. It can easily detect overload, overtemperature, short circuit, no-load, and failed switch errors.
